System parameter group00
PARAMETER DESCRIPTION 74
5.1.12 Motor types selection
 Modify the applicable load type of the inverter.
Parameter
Name
Default
Setting Range
Content
00-23
P.186
Motor types selection
1
0
Normal Duty (ND), on fan and pump duty type.
1
Heavy Duty (HD), apply to other duties.
Motor types selection
 In order to switch to heavy duty setting ( 00-23(P.186)= 1), be sure to perform the following steps. After these
steps are completed, the duty type will be successfully switched.
1. Set 00-23(P.186)=0;
2. Set 00-02=3(P.998=1) to set all parameters to default;
3. Set 00-02=2(P.997=1) to reset inverter.
5.1.13 50/60Hz switch selection
 Select between 50Hz or 60Hz according to different power source frequency or default motor frequency, this
effects all frequency-related parameters.
Parameter
Name
Default
Setting Range
Content
00-24
P.189
50/60 Hz switch
selection
0
0
Frequency related parameter default value is 60Hz.
1
1
Frequency related parameter default value is 50Hz.
50/60Hz switch selection
 The following two steps shows how to set frequency related parameter to 60Hz system (00-24(P.189)=”0”).
1. Set 00-24(P.189)=0;
2. Set 00-02=3(P.998=1) to set all parameters to default, at this point frequency-related parameters of the inverter will be
reset to 60Hz.
 The following parameters are affected:
Group
No.
Name
Group
No.
Name
01-03
P.3
Base frequency
02-51
P.55
Frequency display reference when in the
analog output
01-09
P.20
Accelerate/decelerate reference
frequency
05-03
P.304
Motor rated voltage
02-09
P.38
2-5 maximum operation frequency
05-04
P.305
Motor rated frequency
02-21
P.39
The maximum operation frequency of
terminal 4-5
05-06
P.307
Motor rated rotation speed
06-03
P.66
Stall prevention operation reduction
starting frequency
02-30
P.508
Reserve
10-41
P.701
VF separated voltage digital
Setting
