Shihlin electric SE3 Series User Manual

Application parameter group 10
PARAMETER DESCRIPTION 206
5.11 Application parameter group 10
Group
Parameter
Number
Name
Setting Range
Default
Page
10-00
P.10
DC brake operating
frequency
0～120.00Hz
3.00Hz
210
10-01
P.11
DC brake operating time
0～60.0s
0.5s
210
10-02
P.12
DC brake operating voltage
0～30.0%: 7.5K and below
4.0%
210
0～30.0%: 11K～22K
2.0%
10-03
P.151
Zero-speed control function
selection
0: Off.
0
211
1: In close-loop vector control (00-21(P.300)
/00-22(P. 370) =4) mode do zero-speed; In V/F
close-loop control (00-21(P.300) /00-22(P. 370)
=1) mode do DC voltage breaking.
2: In close-loop vector mode do zero-servo.
10-04
P.152
Voltage at zero-speed
control
0～30.0%: 7.5K and below
4.0%
211
0～30.0%: from 11K to 22K
2.0%
10-05
P.242
DC brake before inverter
start
0: Off
0
212
1: Before starting operate DC brake first.
10-06
P.243
DC brake time before
inverter start
0～60.0s
0.5s
212
10-07
P.244
DC brake voltage before
inverter start
0～30.0%: 7.5K (included) and below
4.0%
212
0～30.0%: 11K～22K
2.0%
10-08
P.150
Restart mode selection
XX0: No frequency search.
0
213
XX1: Direct frequency search
XX2: Decrease voltage mode
X0X: Power on once.
X1X: Start each time.
X2X: Only instantaneous stop and restart
0XX: No rotation direction detection.
1XX: Rotation direction detection.
2XX:00-15(P.78)=0, rotation direction detection；
00-15(P.78)=1/2, no rotation direction detection.
10-09
P.57
Restart idling time
0～30.0s
99999
213
99999: Off.
10-10
P.58
Restart rising time
0～60.0s: 7.5K (included)and below.
5.0s
213
0～60.0s: 11K～22K
10.0s
10-11
P.61
Remote control function
0: Off
0
215
1: Remote control function, frequency save in
memory
2: Remote control function, frequency won’t save
3: Remote control function, frequency won’t save,
clear frequency setting every time STF/STR “turn
off”.
