Analog input and output parameter group 02
PARAMETER DESCRIPTION 97
5.3.2 Analog output terminals AM function selection
 Selects the monitor item for analog output terminal AM.
Parameter
Name
Default
Setting Range
Content
02-04
P.54
Terminal AM output
function
0
0
Output frequency, use 02-51 (P.55) value as 100%.
1
Output current, use 02-52 (P.56) value as 100%.
2
Output DC bus voltage, use the OV trigger voltage as 100%.
3
Output inverter temperature accumulate rising rate, use NTC
trigger level as 100%.
4
Output inverter thermal relay accumulate rate, use the digital
thermal relay trigger level ( 06-00 ( P.9 ) ≠ 0 ) or the thermal
relay on IGBT trigger level ( 06-00 (P.9) = 0) as 100%.
5
Target frequency, use 02-51(P.55) value as 100%.
6
Fixed output, voltage or current output level can be set by
02-54 (P.541)
7
Output voltage, use inverter rated voltage as 100%
8
Excitation current, use motor rated current as 100%. (Valid
only when 00-21(P.300) or 00-22 (P.370) is set to 3~6)
9
Output torque, use two times motor rated torque as
100%.(Valid only when 00-21 (P.300) or 00-22 (P.370) is set
to 3~6)
10
Output power, use two times motor rated power as 100%.
11
High-speed pulse input, use 100KHz as 100%.
12
Motor speed, use 02-51 (P.55) as 100%
13
PLC analog output, for details please refer to SA3 buit-in
PLC manual
Usage of analog output terminal AM

For the voltage/current calibration of terminal AM, please refer to calibration parameter in section 5.3.11 output
terminal AM signal selection and processing.
