Reactor
INVERTER INTRODUCTION 31
3.6.2 No-fuse breaker and magnetic contactor
Inverter model
Motor capacity
Power source capacity
Applicable no-fuse switch
(NFB/MCCB) type
(Shihlin Electric)
Applicable electromagnetic
contactor (MC) type
(Shihlin Electric)
SE3-043-0.4K
440V 0.5HP
1 kVA
BM30SN3P3A
S-P11
SE3-043-0.75K
440V 1HP
2.5 kVA
BM30SN3P5A
S-P11
SE3-043-1.5K
440V 2HP
4.8kVA
BM30SN3P10A
S-P11
SE3-043-2.2K
440V 3HP
6.9kVA
BM30SN3P15A
S-P21
SE3-043-3.7K
440V 5HP
10.4kVA
BM30SN3P20A
S-P21
SE3-043-5.5K
440V 7.5HP
11.5 kVA
BM30SN3P30A
S-P21
SE3-043-7.5K
440V 10HP
16 kVA
BM30SN3P30A
S-P21
SE3-043-11K
440V 15HP
20 kVA
BM60SN3P50A
S-P30T
SE3-043-15K
440V 20HP
27 kVA
BM60SN3P60A
S-P40T
SE3-043-18.5KF
440V 25HP
32 kVA
BM100SN3P75A
S-P40T
SE3-043-22K
440V 30HP
41 kVA
BM100SN3P100A
S-P50T
SE3-023-0.4K
220V 0.5HP
0.5kVA
BM30SN3P5A
S-P11
SE3-023-0.75K
220V 1HP
2.5kVA
BM30SN3P10A
S-P11
SE3-023-1.5K
220V 2HP
4.5kVA
BM30SN3P15A
S-P11
SE3-023-2.2K
220V 3HP
6.4kVA
BM30SN3P20A
S-P11/S-P12
SE3-023-3.7K
220V 5HP
10kVA
BM30SN3P30A
S-P21
SE3-023-5.5K
220V 7.5HP
12kVA
BM60SN3P50A
S-P25
SE3-023-7.5K
220V 15HP
20 kVA
BM100SN3P100A
S-P35T
SE3-023-11K
220V 20HP
28 kVA
BM160SN3P125A
S-P50T
SE3-023-15K
220V 25HP
34 kVA
BM160SN3P160A
S-P60T
SE3-021-0.4K
220V 0.5HP
1 kVA
BM30SN3P3A
S-P11
SE3-021-0.75K
220V 1HP
2.5kVA
BM30SN3P10A
S-P11
SE3-021-1.5K
220V 2HP
4.5kVA
BM30SN3P15A
S-P11
SE3-021-2.2K
220V 3HP
6.9kVA
BM30SN3P15A
S-P11/S-P12
3.6.3 Regenerative Brake Resistor
Voltage
Motor
(KW)
Braking Resistor (10%ED，Braking Torque 125%)
Maximum braking torque limit
Resistor specifications
Minimum
resistance
value(Ω)
Highest total
braking current(A)
Maximum
peak power(KW)
021
0.4
40W 375Ω
220
2
0.6
0.75
75W 200Ω
120
3
1.1
1.5
150W 100Ω
60
6
2.2
2.2
220W 68.2Ω
60
6
2.2
023
0.4
40W 375Ω
220
2
0.6
0.75
75W 200Ω
120
3
1.1
1.5
150W 100Ω
60
6
2.2
2.2
220W 68.2Ω
60
6
2.2
3.7
370W 40.5Ω
40
9
3.2
5.5
550W 27.3Ω
30
12
4.3
7.5
750W 20Ω
20
18
6.5
11
1100W 13.6Ω
13.6
26
9.5
15
1500W 10Ω
10
36
13.0
043
0.4
40W 1500Ω
1000
1
0.5
0.75
75W 800Ω
800
1
0.7
1.5
150W 400Ω
320
2
1.6
2.2
220W 272.8Ω
160
5
3.2
