Basic operation steps for different modes
PRIMARY OPERATION 54
4.3.8 Basic operation steps for combined mode 4(00-16(P.79)＝7)
•
In Combined Mode 4, indicator in
will flash.
Note: 1. For detailed operation procedures for monitor mode, please refer to Section 4.2.
•Target frequency of the inverter is determined by the external terminals “external voltage signal”, “external current
signal”, or “combination of multi-speed stage levels”.
•The inverter starting is activated by communication (including “Reset”). At this point, indicator
RUN
will flash indicating
that the motor is running.
Note: 1. For detailed operation procedures for the monitoring mode, please refer to Section 4.2.3.
2. While the motor is running, the user can enter into the frequency setting mode to change the target frequency for
regulating the motor speed.
•When communication sends the stop instruction, the motor will decelerate until it comes to a full stop.
• Indicator
RUN
will not turn off until the inverter stops the output.
4.3.9 Basic operation steps for combined mode 5(00-16(P.79)＝8)
• In Combined Mode 5, indicatior
will light up.
Note: For detailed operating procedures for monitor mode, please refer to Section 4.2.
•Target frequency of the inverter is set by keypad:
• When RL, RM, RH and REX for multi-speed stage levels are “on”, target frequency is determined by the
combination of multi-speed stage levels (please refer to
04-00~04-14(P.4~P.6 、 P.24~P.27 、
P.142~P.149),
03-00~03-05(P.80~P.84、P.86)).
• When external JOG is “on”, target frequency is determined by 01-13(P.15). Acceleration / deceleration time
is set by the value in 01-14(P.16).
•Inverter starting is triggered by external STF or STR terminals.
Note: 1. For detailed operation procedures for the monitoring mode, please refer to section 4.2.3.
2. While the motor is running, the user can enter frequency setting mode to change the target frequency
for regulating motor speed.
•When digital input terminals output stop signal, the motor will decelerate until it comes to a full stop.
• Indicator
RUN
will not turn off until the inverter stops the output.
4.3.10 Basic operation procedures for the second operation mode(00-16(P.79)＝99999)
In second operation mode, target frequency is determined by 00-17(P.97), and the run command is determined by
00-18(P.109), please refer to Section 5.1.9 Operation mode selection for related description and Section
4.3.1~4.3.5 for related operation method.
