Shihlin electric SE3 Series User Manual

Digital input/ output parameter group03
PARAMETER DESCRIPTION 128
5.4.10 Expanded digital input terminal logic selection
 This function is set in bits, if bit shows 1, it means the correspond terminal is negative logic; if bit shows 0, it means
the correspond terminal is positive logic.
Parameter
Name
Default
Setting Range
Content
03-41
P.567
Expanded digital input
terminal logic
0
0～63
---
Expanded digital input terminal logic
 The definition of each 03-41 (P.567) bit is as follows:
bit
M10M11
M12
M13M14
M15
2
0
2
1
2
2
2
3
2
4
2
5
SLOT expanded
digital input
5.4.11 Expanded digital output terminal function selection
 Detect information generated and send digital signal output during inverter operation.
Parameter
Name
Default
Setting Range
Content
03-42
P.568
Expanded digital output
terminal A10
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-43
P.569
Expanded digital output
terminal A11
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-44
P.570
Expanded digital output
terminal A12
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-45
P.571
Expanded digital output
terminal A13
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-46
P.572
Expanded digital output
terminal A14
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-47
P.573
Expanded digital output
terminal A15
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-48
P.574
Expanded digital output
terminal A16
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
03-49
P.575
Expanded digital output
terminal A17
99999
Same as 03-10(P.40)
Same as 03-10(P.40)
Expanded digital output terminal function
 The function is the same as the digital output function, please refer to Section 5.4.2.
Setting
Setting
