Tension control parameter group 14
PARAMETER DESCRIPTION 259
14-01
(P.601)
is for selecting winding mode,which can be used together with wind/release terminal.When the
switching terminal of the wind/release is invalid，the actual winding mode is the same as the function mode. When
the switching terminal of the wind/release is valid,the actual setting of the winding mode is the same as the setting
of the switching terminal of wind/release.
14-02
(P.602) is
for selecting if tightening material through motor inverse is allowed.If not allowed,inverter will output
torque only when material is moving forward during releasing roll.
14-03
(P.603)
is the mechanical transmission ratio.Mechanical ratio=motor rotation speed/shaft rotation speed.
Mechanical transmission ratio must be properly set during tension control mode.
5.15.2 Tension setting
This part is only related to open-loop mode，set PID setting source via closed-loop mode.
The parameter 14-05(P.605) setting.
The analog value or PULSE input setting.
Zero-speed tension
increase
Taper compensation
correction
Tension setting
The parameters in this part apply only to opened-loop torque mode .
When 14-04
(P.604)
is 0, tension is set through 14-05
(P.605)
.
When 14-04
(P.604)
is 1, set tension via analog value or pulse input terminal. When setting tension by this
method,maximum tension 14-06
(P.606)
must be set.The maximum general analog value setting and the maximum
pulse setting both correspond to the maximum tension.The pulse can be set by the M2 terminal.
