Shihlin electric SE3 Series User Manual

Communication parameter group07
PARAMETER DESCRIPTION 168
5.8.1 Shihlin protocol and Modbus protocol
 These protocols can link and communicate with upper controller through RS-485 communication port of inverter
for parameter setting, monitoring, etc..
Parameter
Name
Default
Setting Range
Content
07-00
P.33
COM1 Communication
protocol selection
1
0
Modbus protocol
1
Shihlin protocol
2
PLC protocol（Effective when using Shilin built-in PLC）
07-01
P.36
COM1 inverter
communication station
number
0
0～254
Maximum inverter connect number is determined by wiring
method and impedance matching. Please set its value to a
non-zero value when using Modbus protocol.
07-02
P.32
COM1 Serial
communication baud
rate
1
0
Baud rate:4800bps
1
Baud rate:9600bps
2
Baud rate:19200bps
3
Baud rate:38400bps
4
Baud rate:57600bps
5
Baud rate:115200bps
07-03
P.48
COM1 data length
0
0
8bit
1
7bit
07-04
P.49
COM1 stop bit length
0
0
1bit
1
2bit
07-05
P.50
COM1 parity check
selection
0
0
No parity check
1
Odd
2
Even
07-06
P.51
COM1 CR/LF selection
1
1
CR only
2
Both CR and LF
07-07
P.154
COM1 Modbus
communication format
4
0
1, 7, N, 2 (Modbus, ASCII)
1
1, 7, E, 1 (Modbus, ASCII)
2
1, 7, O, 1 (Modbus, ASCII)
3
1, 8, N, 2 (Modbus, RTU)
4
1, 8, E, 1 (Modbus, RTU)
5
1, 8, O, 1 (Modbus, RTU)
07-08
P.52
COM1 Number of
communication retries
1
0～10
If communication error times exceed set value of 07-08
(P.52) and 07-10 (P.153) is set to 0, alarm OPT will be
reported.
07-09
P.53
COM1 communication
interval allowed time
99999
0～999.8s
Checking communication timeout with the set value
99999
No timeout check
07-10
P.153
COM1 communication
alarm action
0
0
Alarm and stop freely
1
No alarm and continuing to operation
07-25
P.810
PU communication
protocol selection
1
0
Modbus protocol
1
Shilin protocol
2
PLC protocol（Effective when using Shihlin built-in PLC）
07-26
P.811
PU inverter
communication station
number
0
0～254
Maximum inverter connect number is determined by wiring
method and impedance matching. Please set its value to a
non-zero value when using Modbus protocol.
