PG feedback parameter group 09
PARAMETER DESCRIPTION 200
Group
Parameter
Number
Name
Setting Range
Default
Page
09-11
P.360
Anti-reversal detection pulse
065535
0
203
09-12
P.361
Reversal detection frequency
065535
0
203
09-13
P.124
Expansion card version
Read only
Read
204
09-14
P.363
Z phase correction allowance
0.0°:Off
15.0°
204
0.1°~360.0°:Z phase pulse correction
09-15
P.364
Z phase DV1/DV2 alarm
enabled
0Off
1
204
1Z phase DV1/DV2 alarm valid
09-16
P.386
Encoder signal detection
setting
1 digitPG302L hardware
disconnection check
0Off
1
201
1Valid
2 digitA1/B1 phase sequence
check
0Off
1Valid
5.10.1 PG type selection
PGPulse Generator
Parameter
Name
Default
Setting Range
Content
09-00
P.349
PG type setting
0
0
ABZ
1
ABZ (for synchronous motor)
2
Resolver 1x synchronized motor standard encoder
3
ABZ/UVW synchronized motor standard encoder
PG type setting
Please set the value of parameter 09-00(P.349) according to selected motor and PG card type.
Set 09-00(P.349)=0 when pairing PM motor with normal ABZ photoelectric encoder, inverter will set the pull in
method or high frequency pulse vibration method to obtain PM motor rotors initial magnetic pole start position
according to 11-08(P.328).
PM motor with UVW encoder, set 09-00(P.349)=1. The encoder will send out motor rotor magnetic pole
information when sending power for the first time. Inverter activates PM motor according to initial magnetic pole
position.If error occurs on inverter, sending power once again will be necessary, or else PM motor error will occur.
When PM motor is paired with rotating encoder, 09-00(P.349) should be set to 2. Inverter will read the PM motor
rotor magnetic pole position information every time it sends power or returns.Inverter activates the PM motor
according to the initial magnetic pole position information.
