Shihlin electric SE3 Series User Manual

Motor parameter group 05
PARAMETER DESCRIPTION 143
5.6.2 Motor parameter
 Inverter has built-in standard parameters for motor. Modify the default values according to the actual situation to
conform to the actual values as much as possible.
Parameter
Name
Default
Setting Range
Content
05-01
P.302
Motor rated power
0.00kW
0～650.00kW
---
05-02
P.303
Motor poles
4
0～48
---
05-03
P.304
Motor rated voltage
380/440V
0～510V
440V voltage
220V
0～255V
220V voltage
05-04
P.305
Motor rated frequency
50.00Hz
0～650.00Hz
50Hz system (when 00-24(P.189)=1)
60.00Hz
60Hz system (when 00-24(P.189)=0)
05-05
P.306
Motor rated current
According
to kW
0～500.00A
---
05-06
P.307
Motor rated rotation
speed
1410r/min
0～65000r/min
50Hz system (when 00-24(P.189)=1)
1710r/min
60Hz system (when 00-24(P.189)=0)
05-07
P.308
Motor excitation
current
According
to kW
0～500.00A
---
05-08
P.309
IM motor stator
resistance
According
to kW
0～65000mΩ
---
05-09
P.310
IM motor rotor
resistance
According
to kW
0～65000mΩ
---
05-10
P.311
IM motor leakage
inductance
According
to kW
0～6500.0mH
---
05-11
P.312
IM motor mutual
inductance
According
to kW
0～6500.0mH
---
05-12
P.313
PM motor stator
resistance
According
to kW
0～65000mΩ
---
05-13
P.314
PM motor d-axis
inductance
According
to kW
0～650.00mH
---
05-14
P.315
PM motor q-axis
inductance
According
to kW
0～650.00mH
---
05-15
P.316
PM motor Back-EMF
coefficient
According
to kW
0～6500.0V/krpm
---
05-16
P.317
PM motor Phase Z
origin pulse
compensation
0.0°
0～359.9°
---
