Shihlin electric SE3 Series User Manual

System parameter group00
PARAMETER DESCRIPTION 64
and the parameters in table 1 above will not be restored to default values. After parameters are restored,
00-02
(P.996~P.999)
is reset to 0.

6: User registered parameter 15-00~15-19 and the parameters set in 15-00(P.900)~15-19(P.919) and the
parameters in table 1 above will not be restored to default values. After parameters are restored,
00-02
(P.996~P.999)
is reset to 0
Note: When the parameter is restored to default value or some of the parameters are restored to default value, be sure
to wait for the screen to display , which means that it’s complete, and then perform other operations.
5.1.3 Parameter protection
 It is used to select whether parameters can be written to prevent changing parameter values due to misoperation.
Parameter
Name
Default
Setting Range
Content
00-03
P.77
Selection of parameters
write protection
0
0
Parameters can be written only when the motor stops.
1
Parameters cannot be written.
2
Parameters can also be written when the motor is running.
3
Parameters cannot be read when in password protection.
00-04
P.294
Password parameter
0
0~65535
Write the registered password to decrypt parameter protection.
00-05
P.295
Password setup
0
0~65535
Register password for parameter protection setting.
Selection of parameters write protectio
n

Write parameters only during stop (00-03(P.77)=“0”initial value)
Exception When running, the parameters below can still be written:
Group
No.
Name
Group
No.
Name
00-03
P.77
Selection of parameters write protection
02-18
P.510
The percentage corresponding to the
minimum negative voltage of terminal 2-5
00-07
P.161
Multi-function display
02-04
P.54
Function of terminal AM output
02-19
P.511
The percentage corresponding to the
maximum negative voltage of terminal 2-5
02-05
P.537
Reserve
02-12
P.192
The minimum input positive voltage of 2-5
02-25
P.198
The minimum input current/voltage of 4-5
02-13
P.193
The maximum input positive voltage of 2-5
02-26
P.199
The maximum input current/voltage of 4-5
02-14
P.194
The percentage corresponding to the
minimum positive voltage of terminal 2-5
02-27
P.196
The percentage corresponding to the
minimum input current/voltage of 4-5
02-15
P.195
The percentage corresponding to the
maximum positive voltage of terminal 2-5
02-28
P.197
The percentage corresponding to the
maximum input current/voltage of 4-5
02-16
P.512
The minimum input negative voltage of 2-5
02-34
P.548
Reserve
02-17
P.513
The maximum input negative voltage of 2-5
02-35
P.549
Reserve
02-36
P.546
Reserve
04-13
P.148
Speed14
02-37
P.547
Reserve
04-14
P.149
Speed15
02-39
P.524
HDI input minimum frequency
04-19
P.131
Programmed operation mode speed 1
02-40
P.525
HDI input maximum frequency
04-20
P.132
Programmed operation mode speed 2
02-41
P.522
The percentage corresponding to HDI input
minimum frequency
04-21
P.133
Programmed operation mode speed 3
04-22
P.134
Programmed operation mode speed 4
Setting
