Note: 1. When the motor runs at 50Hz (or 60Hz), the commercial power supply will offer a more efficient operation than
the inverter will. Moreover, during the inverter maintenance/inspection period, the commercial power supply
circuit should be installed to prevent the motor from being stopped for too long.
2. To prevent the inverter from setting off the over-current alarm when changing between the inverter operation
and the commercial power supply operation, the interlock measure has to be taken. Once the motor stops, it will
be activated via the inverter. Switchover and interlock can be carried out through the inverter and a complicated
commercial power supply if commercial power supply switchover sequence function that can send out the signal
for electromagnetic contactor actions is used.
3. This function is only valid under the V/F mode 00-21(P.300)=0.
5.11.12 When input power fail stop function
When the inverter power comes to a sudden failure, regenerative power can maintain the inverter output to
deceleration stop.
When input power
fail stop option
No undervoltage avoidance (If undervoltage or power fail, the
motor decelerates to stop.)
No undervoltage avoidance (If undervoltage or power fail, the
motor decelerates to stop. Motor re-accelerates if power
restores during the deceleration to stop.)
Undervoltage avoidance (If undervoltage or power fail, the
motor decelerates to stop.)
Undervoltage avoidance (If undervoltage or power fail, the
motor decelerates to stop. Motor re-accelerates if power
restores during the deceleration to stop.)
When input power
fail subtracted
frequency at
deceleration start
Normally it can run at the initial value, please adjust according
to the load specification (inertia, torque)
When input power
fail subtraction
starting frequency
When output frequency≥10-35(P.275), Motor decelerates from
“output frequency - 10-34(P.274)”;When output frequency<
10-35(P.275), deceleration from output frequency
Motor decelerates from “output frequency - 10-34(P.274)”
Deceleration time
during input power
failure 1
Set the time from the deceleration start to the 10-38(P.278) set
frequency.
Deceleration time
during input power
failure 2
Set the deceleration time for the frequency range starting at
10-38(P.278) and downward.
When input power
fail deceleration
time switchover
frequency
Set the frequency at which the slope during deceleration
switches from the 10-36(P.276) setting to the 10-37(P.277)
setting.
UV avoidance
voltage gain
Adjust the response level for undervoltage avoidance
operation.
