Shihlin electric SE3 Series User Manual

Analog input and output parameter group 02
PARAMETER DESCRIPTION 91
5.3 Analog input and output parameter group 02
Group
Parameter
Number
Name
Setting Range
Default
Page
02-00
P.500
Terminal 2-5 input function
0: Off
1
96
1: Frequency command
2: Torque command
3: PID target value
4: PID feedback signal
5: Tension target value
6: Line speed
7: Line speed feedback
8: Real-time roll diameter
9: Initial roll diameter
10: Material thickness
11: PTC thermistor
12: PT100 thermistor
13: VF separate function
14: Positive torque limit
15: Negative torque limit
16: Positive/Negative torque limit
17: Regenerative torque limit
02-01
P.501
Terminal 4-5 input function
Same as 02-00
1
96
02-03
P.503
Terminal HDI input function
Same as 02-00
0
96
02-04
P.54
Terminal AM output function
0: Output frequency, use 02-51 (P.55) value as
100%.
0
97
1: Output current, use 02-52 (P.56) value as
100%.
2: Output DC bus voltage, use the OV trigger
voltage as 100%.
3: Output inverter temperature accumulate rising
rate, use NTC trigger level as 100%.
4: Output inverter thermal relay accumulate rate,
use the digital thermal relay trigger level ( 06-00
( P.9 ) ≠ 0 ) or the thermal relay on IGBT trigger
level ( 06-00 (P.9) = 0) as 100%.
5: Target frequency, use 02-51(P.55) value as
100%.
6: Fixed output, voltage or current output level
can be set by 02-54 (P.541)
7: Output voltage, use inverter rated voltage as
100%
8: Excitation current, use motor rated current as
100%. (Valid only when 00-21(P.300) or 00-22
(P.370) is set to 3~6)
