Shihlin electric SE3 Series User Manual

PG feedback parameter group 09
PARAMETER DESCRIPTION 204
5.10.5 Dividing frequency output function
 Multiplier setting of PG card feedback output.
Parameter
Name
Default
Setting Range
Content
09-08
P.357
Frequency division
output setting
1
1～255
Multiplier setting of PG card foutput and feedback
09-09
P.358
Frequency division
filter coefficiency
setting
0
0～255
Frequency division filter coefficiency setting of PG03 setting
Frequency division output function

Parameter 09-08
(P.357)
is the multiplier setting of the PG card feedback and output. If the feedback is 1024PPR,
09-08
(P.357)
setting will be 2, and PG card’s （pulse output）output will be 512PPR.
5.10.6 Electronic gear ratio
 Electronic gear ratio setting for the pulse input of A2/B2 of PG301 card.
Parameter
Name
Default
Setting Range
Content
09-10
P.359
Electronic gear ratio
1.00
0～300.00
---
Electronic gear ratio
 Please refer to parameter 09-07(P.356) for the instructions for 09-10(P.359).
5.10.7 Reverse spin detection
 The relative settings for PM motor prevent reverse rotation
Parameter
Name
Default
Setting Range
Content
09-11
P.360
Reverse spin prevention
detection pulse
0
0～65535
Setting of the pulse of reverse spin detection of PM motor
09-12
P.361
Reverse spin detection
count
0
0～65535
Setting of the number of reverse spin detection of PM
motor
Reverse spin setting
 09-11(P.360) is for the setting of the number of reverse spin detection pulse. When the motor spins continuously in
the opposite direction of the speed command, reverse spin prevention alarm dv4 will be output. Set 09-11(P.360) to
0 when the direction of the load is opposite to the speed command, which cancels the reverse spin prevention
alarm. It is only valid in PM motor closed-loop vector control mode.
 09-12(P.361) is for the setting of the number of reverse spin detection. When detect acceleration direction is
opposite from speed command direction for 09-12(P.361) times, trigger DV3(reverse spin) alarm. When
09-12(P.361)=0, reverse spin prevention alarm will be canceled. It is only valid in Pm motor closed-loop vector
control mode.
Setting
Setting
Setting
