Basic operation steps for different modes
PRIMARY OPERATION 52
4.3.3 Basic operation steps for JOG mode (00-16(P.79)＝0 or 1)
•Switch operation mode to JOG mode and indicator in
will light up, the display shows .
Note: 1. For detailed operating procedures for the monitor mode, please refer to section 4.2.
• Press or to run the motor. At this point, indicator in RUN will glitter, indicating that the motor
is running.
• Release or to decelerate the motor until it comes to a full stop. Indicator in RUN will not
turn off until the inverter stops the output.
Note: 1. For detailed operating procedures for monitor mode, please refer to section 4.2.3.
2. In JOG mode, target frequency is the value of 01-13(P.15), and the acceleration / deceleration time is
the value of 01-14(P.16). Please refer to 01-13(P.15) in chapter 5.
4.3.4 Basic operation steps for communication mode (00-16
(P.79)
＝3)
In communication mode, user can set parameters and run/stop or reset inverters by communication. Please
refer to
Communication function related parameters
for details
.
4.3.5 Basic operation steps for combined mode 1 (00-16(P.79)＝4)
•
In Combined Mode 1, indicator
will light up.
Note: 1. For detailed operation procedures for monitor mode, please refer to section
4.2.
•Enter frequency setting mode and write target frequency into memory.
Note: For setting details, please refer to section 4.2.4.
•Set target frequency by PU302 keypad and start the inverter by digital input terminals.
• At this point, indicator in
RUN will flash, indicating that the motor is running.
Note: For detailed operation procedures for monitor mode, please refer to section 4.2.3.
•When digital input terminals output stop signals, motor will decelerate until it comes to a full stop.
• Indicator in
RUN will not turn off until the inverter stops outputting.
