Appendix 1
APPENDIX 276
7. APPENDIX
7.1 Appendix 1 Parameter table
7.1.1 P parameter number sequence
Parameter
Number
Group
Name
Setting Range
Default
Page
P.0
01-10
Torque boost
0.75K: 030.0%
6.0%
82
1.5K3.7K: 030.0%
4.0%
5.5K7.5K: 030.0%
3.0%
11K22K: 030.0%
2.0%
P.1
01-00
Maximum frequency
22K and below: 0.0001-02(P.18)Hz
120HZ
79
P.2
01-01
Minimum frequency
0120.00Hz
0.00Hz
79
P.3
01-03
Base frequency
50Hz system setting: 0650.00Hz
50.00Hz
79
60Hz system setting: 0650.00Hz
60.00Hz
P.4
04-00
Speed1(high speed)
0650.00Hz
60.00Hz
133
P.5
04-01
Speed2(medium
speed)
0650.00Hz
30.00Hz
133
P.6
04-02
Speed3(low speed)
0650.00Hz
10.00Hz
133
P.7
01-06
Acceleration time
3.7K and below: 0~360.00s/0~3600.0s
5.00s
80
5.5K and above:0~360.00s/0~3600.0s
20.00s
P.8
01-07
Deceleration time
3.7K and below:0~360.00s/0~3600.0s
5.00s
80
5.5K~7.5K:0~360.00s/0~3600.0s
10.00s
11K and above: 0~360.00s/0~3600.0s
30.00s
P.9
06-00
Electronic thermal relay
capacity
0~500.00A
0.00A
151
P.10
10-00
DC brake operating
frequency
0120.00Hz
3.00Hz
210
P.11
10-01
DC brake operating
time
060.0s
0.5s
210
P.12
10-02
DC brake operating
voltage
030.0%: 7.5K and below
4.0%
210
030.0%: 11K22K
2.0%
P.13
01-11
Starting frequency
060.00Hz
0.50Hz
83
P.14
01-12
Load pattern selection
0: For constant torque loads (conveyor belt,etc.)
0
83
1: For variable torque loads (fans and pumps, etc.)
23: For Lifting loads
4: Multipoint V/F curve
5~13: Special two-point V/F curve
14: V/F complete detached mode
15: V/F semidetached mode
P.15
01-13
JOG frequency
0650.00Hz
5.00Hz
86
P.16
01-14
JOG acceleration/
deceleration time
0360.00s/03600.0s
0.50s
86
P.17
02-20
Terminal 4-5 signal
range selection
0: Signal sampling range from 4~20mA.
0
105
1: Signal sampling range from 010V.
2: Signal sampling range from 05V.
