Shihlin electric SE3 Series User Manual

Reactor
INVERTER INTRODUCTION 33
 AC output reactor
Inverter model
Recommended reactor
Shihlin Type
Rated current (A)
Inductance(mH)
SE3-043-0.4K
SH-OCL-0005-02800
5
2.8
SE3-043-0.75K
SH-OCL-0005-02800
5
2.8
SE3-043-1.5K
SH-OCL-0005-02800
5
2.8
SE3-043-2.2K
SH-OCL-0005-02800
5
2.8
SE3-043-3.7K
SH-OCL-0007-01900
7
1.9
SE3-043-5.5K
SH-OCL-0010-01400
10
1.4
SE3-043-7.5K
SH-OCL-0015-00930
15
0.93
SE3-043-11K
SH-OCL-0020-00700
20
0.70
SE3-043-15K
SH-OCL-0030-00460
30
0.46
SE3-043-18.5K
SH-OCL-0040-00350
40
0.35
SE3-043-22K
SH-OCL-0050-00280
50
0.28
SE3-023-0.4K
SH-OCL-0005-02800
5
2.8
SE3-023-0.75K
SH-OCL-0005-02800
5
2.8
SE3-023-1.5K
SH-OCL-0005-02800
5
2.8
SE3-023-2.2K
SH-OCL-0010-01400
10
1.4
SE3-023-3.7K
SH-OCL-0020-00350
20
0.35
SE3-023-5.5K
SH-OCL-0030-00230
30
0.23
SE3-023-7.5K
SH-OCL-0030-00230
30
0.23
SE3-023-11K
SH-OCL-0040-00180
40
0.18
SE3-023-15K
SH-OCL-0060-00120
60
0.12
SE3-021-0.4K
SH-OCL-0005-02800
5
2.8
SE3-021-0.75K
SH-OCL-0005-02800
5
2.8
SE3-021-1.5K
SH-OCL-0005-02800
5
2.8
SE3-021-2.2K
SH-OCL-0010-01400
10
1.4
 DC reactor
Inverter model
Recommended reactor
Shihlin Type
Rated current (A)
Inductance(mH)
SE3-043-5.5K
SH-DCL-0014-03450
14.0
3.45
SE3-043-7.5K
SH-DCL-0020-02380
20.4
2.38
SE3-043-11K
SH-DCL-0027-01770
27.5
1.77
SE3-043-15K
SH-DCL-0034-01440
33.9
1.44
SE3-043-18.5K
SH-DCL-0040-01210
40.3
1.21
SE3-043-22K
SH-DCL-0055-00900
55.0
0.90
SE3-023-5.5K
SH-DCL-0033-00860
33.4
0.86
SE3-023-7.5K
SH-DCL-0048-00600
48.1
0.60
SE3-023-11K
SH-DCL-0065-00450
64.7
0.45
SE3-023-15K
SH-DCL-0080-00360
79.9
0.36
