Protection parameter group06
PARAMETER DESCRIPTION 157
5.7.8 Input phase loss protection
 Turn on input phase failure protection.
Parameter
Name
Default
Setting Range
Content
06-13
P.281
Input phase loss
protection
0
0
Off
1
When input phase loss, inverter stops and alarms IPF(for
frame C/D only)
Input phase loss protection

When 06-13(P.281)=1, input phase loss protection is on; when input power is out of phase or three phases are
imbalance, inverter will trigger alarm IPF. Frame A/B are not equipped with IPF function.
5.7.9 Output short circuit protection function
 Turn on output short circuit protection function.
Parameter
Name
Default
Setting Range
Content
06-14
P.287
SCP Short circuit
protection function
1
0
Off
1
When output side is short, inverter stops and alarms SCP.
Output Short circuit protection function

If 06-14(P.287) is set to 0, output side short circuit protection function will be off.
 If 06-14(P.287)=1, output short circuit protection is on, and when a short circuit on the output side is detected,
inverter “SCP” alarm will trigger.
5.7.10 PTC protection selection
 Set how inverter will operate after PTC detection.
Parameter
Name
Default
Setting Range
Content
06-15
P.533
PTC alarm action
0
0
Alarm and continue to run
1
Alarm and decelerate to stop
2
Alarm and stop freely
3
No alarm
06-16
P.534
Percentage of PTC
level
0.0%
0
Off
0.1%~100.0%
Action level of PTC function, 100% corresponds to
maximum analog input.
PTC level
 Set analog input terminal 2-5/4-5 (02-00(P.500)/02-01(P.501)) to 11 (positive temperature coefficient thermistor
(PTC) input value). This parameter is defined as action level of PTC function, and 100% corresponds to maximum
analog input value
Setting
Setting
Setting
