Digital input/ output parameter group03
PARAMETER DESCRIPTION 117
5.4.1 Digital input terminals function selection
 Use the following parameters to change the digital input terminal functions. Each terminal may choose any
function between 0~71 (Note 1)
Parameter
Name
Default
Setting Range
Content
03-00
P.83
Terminal STF input
function
0
0
STF(Inverter runs forward)
1
STR(Inverter runs reverse)
2
RL(Multi-speed low speed)
3
RM(Multi-speed medium speed)
4
RH(Multi-speed high speed)
5
AU( Analog terminal 4-5 high priority)
6
OH External thermal relay actuate
7
MRS(Stops inverter output immediately)
8
RT(Inverter second function)
9
EXT(External JOG)
10
STF+EXJ
11
STR+EXJ
12
STF+RT
13
STR+RT
14
STF+RL
15
STR+RL
16
STF+RM
17
STR+RM
18
STF+RH
19
STR+RH
20
STF+RL+RM
21
STR+RL+RM
22
STF+RT+RL
23
STR+RT+RL
24
STF+RT+RM
25
STR+RT+RM
26
STF+RT+RL+RM
27
STR+RT+RL+RM
28
RUN(Inverter runs forward)
29
STF/STR(use with RUN signal,when ON, motor runs
reverse；when OFF, motor runs forward)
30
RES(External reset function)
31
STOP(Use as three line control with RUN signal and STF
-STR signal)
32
REX(Extend multi-speed to 16 levels)
33
PO(In “external mode", run programmed operation)
