Shihlin electric SE3 Series User Manual

Nameplate instruction
DELIVERY CHECK 15
2. DELIVERY CHECK
Each SE3 inverter has been checked thoroughly before delivery, and is carefully packed to prevent any mechanical
damage. Please check for the following when opening the package.
• Check whether the product was damaged during transportation.
• Whether the model of inverter is the same with what is shown on the package.
2.1 Nameplate instruction
Rated input:ND 3.2A HD 3.0A
Type
Serial NO.
MFG NO.
Rated output:ND 3.0A HD 2.7A
Rated output voltage,rated output
current,rated output frequency
Degree of protection
MODEL : SE3-043-0.75K
Suzhou Shihlin Electric & Engineering Co.,Ltd
S/N :
O/N : SE31502010
MOTOR RATING : 0.75kW
INPUT : AC 3PH 380-480V 3.0A/3.2A 50/60Hz
OUTPUT : AC 3PH 0-480V 2.7A/3.0A 0-599Hz
IP20
Suitable motor:HD 0.75kW
2.2 Type instruction
SE3-043-0.75K -
XY
NoneGeneral model
- XYCustomer motor or dedicated motor or region difference
Suitable motor
：
0.75K=0.75kW
......
Input voltage 043:440V 3-PHASE
023:220V 3-PHASE
Product series
021:220V 1-PHASE
2.3 Order code description
Example:
Inverter specification
Specification description
Order code
SE3-043-1.5K
SE3 series 440V 1.5KW inverter
SNKSE30431R5K
SE3-043-7.5K
SE3 series 440V 7.5KW inverter
SNKSE30437R5K
SE3-043-15K
SE3 series 440V 15KW inverter
SNKSE304315K
