Basic parameter group 01
PARAMETER DESCRIPTION 89
Parameter
Name
Default
Setting Range
Content
01-29
P.163
Output voltage 2 of
middle frequency
0.0%
0～100.0%
---
01-30
P.164
Middle frequency 3
99999
0～650.00Hz
---
99999
Off
01-31
P.165
Output voltage 3 of
middle frequency
0.0%
0～100.0%
---
01-32
P.166
Middle frequency 4
99999
0～650.00Hz
---
99999
Off
01-33
P.167
Output voltage 4 of
middle frequency
0.0%
0～100.0%
---
01-34
P.168
Middle frequency 5
99999
0～650.00Hz
---
99999
Off
01-35
P.169
Output voltage 5 of
middle frequency
0.0%
0～100.0%
---
Middle frequency, output voltage of middle frequency
 Please refer to the description for 01-12(P.14)=4 in Section 5.2.6 Load pattern selection.
5.2.12 S pattern time
 It is used to set the acceleration time of S pattern acceleration/deceleration.
Parameter
Name
Default
Setting Range
Content
01-36
P.255
S curve time at the
beginning of
acceleration
0.20s
0～25.00s/
0～250.0s
01-08(P.21)=0/
01-08(P.21)=1
01-37
P.256
S curve time at the end
of acceleration
99999
0～25.00s/
0～250.0s
01-08(P.21)=0/
01-08(P.21)=1
99999
Not selected.
01-38
P.257
S curve time at the
beginning of
deceleration
99999
0～25.00s/
0～250.0s
01-08(P.21)=0/
01-08(P.21)=1
99999
Not selected.
01-39
P.258
S curve time at the end
of deceleration
99999
0～25.00s/
0～250.0s
01-08(P.21)=0/
01-08(P.21)=1
99999
Not selected.
Setting
