Shihlin electric SE3 Series User Manual

Motor parameter group 05
PARAMETER DESCRIPTION 140
Group
Parameter
Number
Name
Setting Range
Default
Page
05-38
P.394
Second motor inertia
0 ~ 6500.0kg. cm2: 5.5k and below
99999
147
0 ~ 65000kg. cm2: 7.5k ~ 22K model
9999
05-39
P.395
Second motor load inertia ratio
0~600.0
99999
147
9999
5.6.1 Motor parameter automatic measurement
 By accurate motor parameter measuring function, realize motor high-performance vector control.
Parameter
Name
Default
Setting Range
Content
05-00
P.301
Motor specifications
automatic
measurement
0
0
Off
1
Induction motor specifications automatic measurement 1
(Run motor to measure)
2
Induction motor specifications automatic measurement 2
(Don’t run motor to measure)
3
Induction motor specifications automatic measurement
(Measure when operating)
4
Reserved
5
Induction motor specifications automatic measurement 3
(Don’t run motor to measure)
8
Synchronous motor specifications automatic measurement
(Run motor to measure)
9
Synchronous motor phase Z position automatic
measurement (Run motor to measure)
10
Synchronous motor rotation inertia automatic measurement
(Run motor to measure)
Motor parameter automatic measurement

If 00-21(P.300)=0, inverter operate normally according to V/F curve without automatic measuring motor
parameters.

When controlling induction motor by general flux vector control, please set 00-21(P.300) as 2. Voltage will
increase to compensate for the frequency change when the motor load increases.

To do induction motor parameter automatic measurement function, in PU mode set 05-00
(P.301)
as 1, 2 or 5, and
press forward or reverse rotation key. During measurement, keypad will flash and display “TUN”. If measurement
fails, keypad will flash “FAL” for three seconds.

Automatic induction motor parameters measurement includes the following steps:
Setting
