Motor parameter group 05
PARAMETER DESCRIPTION 139
Group
Parameter
Number
Name
Setting Range
Default
Page
05-15
P.316
PM motor Back-EMF coefficient
0～6500.0V/krpm
According
to kW
143
05-16
P.317
PM motor Phase Z origin pulse
compensation
0～359.9°
0.0°
143
05-17
P.318
Motor inertia
0～6500.0kg. cm2: 5.5K and below
According
to kW
145
0～65000kg.cm2: 7.5K~ 22kW
05-18
P.319
Load inertia ratio
0~600.0
1.0
145
05-19
P.391
Inertia identification speed limit
0~100%
50%
145
05-20
P.392
Acceleration and deceleration time
of inertia identification
0～20.0s
2.0s
145
05-21
P.393
Operation mode of inertia
identification
0: one direction rotation
1
145
1: both direction rotation
05-22
P.332
Second motor rated power
0～650.00kW
99999
146
99999
05-23
P.333
Second motor poles
0～256
99999
146
99999
05-24
P.334
Second motor rated voltage
440 Voltage：0～510V
99999
146
220 Voltage： 0~255V
99999
05-25
P.335
Second motor rated frequency
0～650.00Hz
99999
146
99999
05-26
P.336
Second motor rated current
0~500.00A
99999
146
99999
05-27
P.337
Second motor rated rotation speed
0～65000r/min
99999
146
99999
05-28
P.338
Second motor excitation current
0~500.00A
99999
146
99999
05-29
P.339
Second motor (IM)stator
resistance
0～65000mΩ
99999
146
99999
05-30
P.340
Second motor (IM)rotor resistance
0～65000mΩ
99999
146
99999
05-31
P.341
Second motor (IM)leakage
inductance
0～6500.0mH
99999
146
99999
05-32
P.342
Second motor (IM)mutual
inductance
0～6500.0mH
99999
146
99999
05-33
P.343
Second motor (PM) stator
resistance
0～65000mΩ
99999
146
99999
05-34
P.344
Second motor (PM) d-axis
inductance
0～650.00mH
99999
146
99999
05-35
P.345
Second motor (PM)q-axis
inductance
0～650.00mH
99999
146
99999
05-36
P.346
Second motor (PM) Back-EMF
coefficient
0～6500.0V/krpm
99999
146
99999
05-37
P.347
Second motor (PM) Phase Z origin
pulse compensation
0～359.9°
99999
147
99999
