Communication parameter group07
PARAMETER DESCRIPTION 183
 Table for parameter recovery
Data
content
P parameter
operation
Communication
p parameter
(Note 1)
Table 1
(Note 2)
Table 2
(Note 2)
User
registered
parameter
Other p
parameter
Error
code
H5A5A
00-02=4(P.999=1)
o
x
x
o
o
x
H5566
00-02=5(P.999=2)
o
x
o
x
o
x
H5959
00-02=6(P.999=3)
o
x
x
x
o
x
H9966
00-02=3(P.998=1)
o
x
o
o
o
x
H9696
Communication 999 1
x
x
x
o
o
x
H99AA
Communication 999 2
x
x
o
x
o
x
H9A9A
Communication 999 3
x
x
x
x
o
x
H55AA
Communication 998
x
x
o
o
o
x
HA5A5
00-02=1(P.996=1)
x
x
x
x
x
o
Note: 1. Communication P parameters includes 07-02(P.32), 07-00(P.33), 07-01(P.36), 07-03(P.48)~ 07-09(P.53),
00-16(P.79), 07-10(P.153) and 07-07(P.154).
2. Table 1 and table 2 refer to Section 5.1.2 table1 and table 2.
 Special monitor code table
Information
Content
Unit
H0000
Monitor digital input terminal state.
Note.1
H0001
Monitor digital output terminal state.
Note. 2
H0002
Monitor voltage across terminal 2-5.
0.01V
H0003
Monitor voltage/current across terminal 4-5.
0.01A/0.01V
H0004
Monitor voltage across terminal AM-5.
0.01V
H0005
Monitor DC bus voltage value.
0.1V
H0006
Monitor electronic thermal accumulation rate
---
H0007
Inverter temperature rising accumulation rate
0.01
Item
Shihlin
protocol
command
code
Modbus
command
code
Modbus
address
Data content and function description
Monitor
Frequency
setup
EEPROM
H73
H6D
H03
H1009
H1002
H0000~HFDE8(two decimal points when 00-08=0;
one decimal point when non-zero)
RAM
Output frequency
H6F
H1003
H0000~H9C40(same as above)
Output current
H70
H1004
H0000~HFFFF(two decimal points)
Output voltage
H71
H1005
H0000~HFFFF(two decimal points)
Alarm content
H74
H1007
H0000~HFFFF: last two alarm error code
H74/H1007: Error code 1 and 2;
b15 b8 b7 b0
Error code 2
Error code 1
H75/H1008: Error code 3 and 4;
b15 b8 b7 b0
Error code 4
Error code 3
For error codes, please refer to error code list in
parameter 06-40~06-43.
H75
H1008
