Communication parameter group07
PARAMETER DESCRIPTION 182
Item
Shihlin
protocol
command
code
Modbus
command code
Modbus
address
Data content and function description
Monitor the INV
real-time data
---
H03
H1014~H102F
Modbus address is as follows:
H1014: digital input terminal state.
H1015: digital output terminal state.
H1016: terminal 2-5 analog input voltage
H1017: terminal 4-5 analog input current/voltage
H1018: AM-5 terminal output voltage/current
H1019: DC bus voltage
H101A: inverter electronic thermal accumulation rate
H101B: inverter output wattage
H101C: inverter temperature rising accumulation rate
H101D: inverter NTC temperature accumulation rate
H101E: motor electronic thermal accumulation rate
H101F: PID control target pressure
H1020: PID control feedback pressure
H1021: Motor speed (Hz)
H1022: terminal M2 input frequency
H1023: reserved
H1024: reserved
H1025: inverter output torque
H1026: reserved
H1027: EP301 expansion card version number
H1028: power factor
H1029: output power
H102A：Synchronous motor rotor pole position
H102B：Motor speed (RPM)
H102C：PG feedback speed
H102D：Motor rotor position (Z phase is 0)
H102E：PG card A1B1 feedback pulse number
H102F：PG card A2B2 given number of pulses
Page
change for
parameter
reading and
writing
Read
H7F
---
---
P mode:
H0000: P.0~P.99;
H0001: P.100~P.199;
H0002: P.200~P.299;
H0003: P.300~P.399;
H0004: P.400~P.499;
H0005: P.500~P.599;
H0006: P.600~P.699
H0007: P.700~P.799
H0008: P.800~P.899
H0009: P.900~P.999
H000A: P.1000~P.1099
H000B: P.1100~P.1199
H000C: P.1200~P.1299
Parameter group mode:
H0064: 00-00~00-99;
H0065: 01-00~01-99;
H0066: 02-00~02-99;
H0067: 03-00~03-99;
H0068: 04-00~04-99;
H0069: 05-00~05-99;
H006A: 06-00~06-99
H006B: 07-00~07-99
H006C: 08-00~08-99
H006D: 09-00~09-99
H006E: 10-00~10-99
H006F: 11-00~11-99
H0070: 12-00~12-99
H0071: 13-00~13-99
H0072: 14-00~14-99
H0073: 15-00~15-99
Write
HFF
