Shihlin electric SE3 Series User Manual

Analog input and output parameter group02
PARAMETER DESCRIPTION 92
Group
Parameter
Number
Name
Setting Range
Default
Page
02-04
P.54
Terminal AM output function
9: Output torque, use two times motor rated
torque as 100%.(Valid only when 00-21 (P.300)
or 00-22 (P.370) is set to 3~6)
0
97
10: Output power, use two times motor rated
power as 100%.
11: High-speed pulse input, use 100KHz as
100%.
12: Motor speed, use 02-51 (P.55) as 100%
13：PLC analog output, for details please refer to
SA3 built-in PLC manual
02-06
P.185
Proportion linkage gain
0～100%
0%
98
02-07
P.240
Auxiliary frequency
0: Off
0
99
1: Output frequency = basic frequency + auxiliary
frequency (given by terminal 2-5)
2: Output frequency = basic frequency + auxiliary
frequency (given by terminal 4-5)
3: Output frequency = basic frequency - auxiliary
frequency (given by terminal 2-5)
4: Output frequency = basic frequency - auxiliary
frequency (given by 4-5 terminal)
5: Output frequency = proportional linkage signal
(given by terminal 2-5)
6: Output frequency = proportional linkage signal
(given by terminal 4-5)
02-08
P.73
Terminal 2-5 signal range
selection
0: Signal sampling range from 0 ~5V.
1
99
1: Signal sampling range from 0 ~10V.
2: Signal sampling range from 0 ~ -5V.
3: Signal sampling range from 0 ~ -10V.
4: Signal sampling range from -5～+5V.
5: Signal sampling range from -10～+10V.
02-09
P.38
Terminal 2-5 maximum
running frequency
50Hz system: 1.00～650.00Hz
50.00Hz
100
60Hz system: 1.00～650.00Hz
60.00Hz
02-10
P.60
Terminal 2-5 filter time
0～2000ms
30ms
100
02-11
P.139
Terminal 2-5 voltage signal
bias rate
-100.0%~100.0%
0.0%
100
02-12
P.192
Terminal 2-5 minimum input
positive voltage
0～10.00V
0.00V
100
02-13
P.193
Terminal 2-5 maximum input
positive voltage
0～10.00V
10.00V
100
02-14
P.194
Percentage corresponds to
terminal 2-5 minimum
positive voltage
-100.0%～100.0%
0.0%
100
-400.0%～400.0%(02-00(P.500)= 2/14/15/16/17)
