Shihlin electric SE3 Series User Manual

Analog input and output parameter group 02
PARAMETER DESCRIPTION 93
Group
Parameter
Number
Name
Setting Range
Default
Page
02-15
P.195
Percentage corresponds to
terminal 2-5 maximum
positive voltage
-100.0%～100.0%
100.0%
100
-400.0%～400.0%(02-00(P.500)= 2/14/15/16/17)
02-16
P.512
Terminal 2-5 minimum input
negative voltage
0～10.00V
0.00V
100
02-17
P.513
Terminal 2-5 maximum input
negative voltage
0～10.00V
0.00V
100
02-18
P.510
Percentage corresponds to
terminal 2-5 minimum
negative voltage
-100.0%～100.0%
0.0%
100
-400.0%～400.0%(02-00(P.500)= 2/14/15/16/17)
02-19
P.511
Percentage corresponds to
terminal 2-5 maximum
negative voltage
-100.0%～100.0%
0.0%
100
-400.0%～400.0%(02-00(P.500)= 2/14/15/16/17)
02-20
P.17
Terminal 4-5 signal range
selection
0: Signal sampling range from 4~20mA.
0
105
1: Signal sampling range from 0～10V.
2: Signal sampling range from 0～5V.
02-21
P.39
Terminal 4-5 maximum
operation frequency
50Hz system: 1.00～650.00Hz
50.00Hz
105
60Hz system: 1.00～650.00Hz
60.00Hz
02-22
P.528
Terminal 4-5 filter time
0～2000ms
30ms
105
02-23
P.505
Terminal 4-5 current/ voltage
signal bias rate
-100.0%～100.0%
0.0%
106
02-24
P.184
Terminal 4-5 disconnect
selection
0: Off
0
106
1: Inverter decelerates to 0Hz, muti-function
digital output terminal set off alarm
2: Inverter stops immediately, and keypad
displays “AEr” alarm
3: Inverter runs continuously according to the
frequency command before disconnection.
Digital output terminal will set off alarm.
02-25
P.198
Terminal 4-5 minimum input
current/ voltage
0～20.00mA
4.00mA
106
02-26
P.199
Terminal 4-5 maximum input
current/ voltage
0～20.00mA
20.00mA
106
02-27
P.196
Percentage corresponds to
terminal 4-5 minimum input
current/ voltage
-100.0%～100.0%
0.0%
106
-400.0%～400.0%(02-00(P.500)= 2/14/15/16/17)
