Shihlin electric SE3 Series User Manual

Analog input and output parameter group 02
PARAMETER DESCRIPTION 95
Group
Parameter
Number
Name
Setting Range
Default
Page
02-44
P.543
Terminal FM output function
selection
10: Output power, use two times motor rated
power as 100%.
0
109
11: High-speed pulse input, use 100KHz as
100%.
12: Motor speed, use 02-51 (P.55) as 100%
02-45
P.64
Terminal AM output signal
selection
0: Output 0~10V across terminal AM-5.
0
109
1: Reserved
2: Output 0~20mA across AM-5.
3: Output 4~20mA across AM-5.
02-46
P.191
Terminal AM output gain
0～1024
935
109
02-47
P.190
Terminal AM output bias
0～1024
0
109
02-51
P.55
Maximum analog output
frequency reference
50Hz system: 1.00～650.00Hz
50.00Hz
111
60Hz system: 1.00～650.00Hz
60.00Hz
02-52
P.56
Maximum analog output
current reference
0~500.00A
Accordin
g to type
111
02-54
P.541
Terminal AM/FM fixed output
level
0～100.0%
0.0%
111
02-55
P.592
PT100 thermistor voltage
level 1
0～10.00V
5.00V
111
02-56
P.593
PT100 thermistor voltage
level 2
0～10.00V
7.00V
111
02-57
P.594
PT100 thermistor level 1
frequency
0～650.00Hz
0.00Hz
111
02-58
P.595
PT100 thermistor level 1
delay time
0～6000s
60s
111
02-59
P.187
FM calibration coefficient
0～9998
450
112
