Shihlin electric SE3 Series User Manual

Protection parameter group06
PARAMETER DESCRIPTION 149
Group
Parameter
Number
Name
Setting Range
Default
Page
06-13
P.281
Input phase loss protection
0: Off
0
157
1: When input phase loss, inverter stops and
alarms IPF.(For Frame C/D only)
06-14
P.287
SCP Short circuit protection
function
0: Off
1
157
1: When output side is short, inverter stops and
alarms SCP.
06-15
P.533
PTC alarm action
0: Alarm and continue to run
0
157
1: Alarm and decelerate to stop
2: Alarm and stop freely
3: No alarm
06-16
P.534
Percentage of PTC level
0～100.0%
0.0%
157
06-17
P.261
Maintenance alarm function
0: Off
0
158
1～9998day: Used to set the time for
maintenance alarm output signal
06-18
P.280
Short circuit to ground
detection when starting
0: Off
0
158
1: When given run command to inverter, inverter
detects short circuit to ground
06-19
P.282
GF detection level when
running
0~100.0%
50.0%
158
06-20
P.262
Output phase loss
protection
0: Off
0
159
1: When output phase loss, inverter stops and
alarms LF.
06-21
P.705
Low voltage level
155～220V: 220V inverter type
155V
159
310～440V: 440V inverter type
310V
06-22
P.706
Regenerative brake
operation level
205～400V: 220V inverter type
360V
159
410～800V: 440V inverter type
720V
06-23
P.707
Voltage stall level
205～400V: 220V inverter type
380V
159
410～800V: 440V inverter type
760V
06-24
P.708
Capacitor lifetime detection
0: Off
0
160
1: When the power is OFF, start to detect the
lifetime of capacitor on main circuit.
06-25
P.709
Capacitor lifetime detection
level
0～100.0%
100.0%
160
06-26
P.710
Capacitor lifetime detection
result
0: Normal.
Read
160
1: Electrolytic capacitor abnormal.
06-27
P.292
Total inverter operation
time (minutes)
0～1439 min
0min
161
06-28
P.293
Total inverter operation
time (days)
0～9999 day
0day
161
06-29
P.296
Total inverter power on time
(minutes)
0～1439min
0min
161
06-30
P.297
Total inverter power on time
(days)
0～9999 day
0day
161
06-31
P.298
Output power(lower 16 bit)
Read only
Read
161
