Shihlin electric SE3 Series User Manual

Protection parameter group06
PARAMETER DESCRIPTION 162
Parameter
Name
Default
Setting Range
Content
06-42
P.290
Alarm record
message query
0
0～10
Alarm
message of
No. 06-40
(P.288)
06-42 (P.290) =1, 06-43 (P.291) displays
frequency when 06-40 (P.288) alarm.
06-42 (P.290) =2, 06-43 (P.291) displays current
when 06-40 (P.288) alarm.
06-42 (P.290) =3, 06-43 (P.291) displays output
voltage when 06-40 (P.288) alarm.
06-42 (P.290) =4, 06-43 (P.291) displays
temperature rising accumulation rate when 06-40
(P.288) alarm.
06-42 (P.290) =5, 06-43 (P.291) displays PN
voltage when 06-40 (P.288) alarm.
06-42 (P.290) =6, 06-43 (P.291) displays total
inverter operation time when 06-40 (P.288) alarm.
06-42 (P.290) =7, 06-43 (P.291) displays inverter
operation status code when 06-40 (P.288) alarm.
06-42 (P.290) =8, 06-43 (P.291) displays dates
(years and months) when 06-40 (P.288) alarm.
06-42 (P.290) =9, 06-43 (P.291) displays dates
(days and hours) when 06-40 (P.288) alarm.
06-42 (P.290) =10, 06-43 (P.291) displays dates
(minutes and seconds) when 06-40 (P.288) alarm.
06-43
P.291
Alarm record
message display
Read
only
Read only
Alarm query function

User can read this parameter to know previous 12 alarms and their corresponding information such as frequency,
current and voltage.
Alarm number
recorded by this parameter and status information when alarm occurs will be
cleared if perform 00-02=1
(P.996=1)
operation.
 If parameters 06-40(P.288) and 06-42(P.290) are both 0, 06-41(P.289) and 06-43(P.291) will also display 0.

06-41 (P.290) and 06-43 (P.291) will only work if 06-40 (P.288) has been set. For example, if 06-40 (P.288) =3,
06-41(P.290) =2 is set, then 06-42 (P.289) displays alarm number of alarm E3 and 06-43 (P.291) displays current
value of alarm E3.
Alarm number corresponded alarm condition:
Abnormal
code
Alarm
type
Abnormal
code
Alarm
type
Abnormal
code
Alarm
type
Abnormal
code
Alarm
type
Abnormal
code
Alarm
type
00
No alarm
32
OV1
49
THN
82
IPF
144
OHT
16
OC1
33
OV2
50
NTC
97
OLS
160
OPT
17
OC2
34
OV3
64
EEP
98
OL2
179
SCP
18
OC3
35
OV0
---
---
---
---
192
CPU
19
OC0
48
THT
66
PID
129
AErr
193
CPR
209
PG1
210
PG2
211
PG3
212
bEb
213
PTC
51
NTC2
52
NTC3
53
NTC4
54
NTC5
55
NTC6
56
NTC7
57
NTC8
216
dv1
217
dv2
215
dv3
214
dv4
84
LF
85
HDC
86
ADE
113
rAE
128
GF
---
---
195
EbE1
---
---
---
---
209
PG1
210
PG2
211
PG3
212
bEb
213
PTC
208
PG0
161
PUE
162
CbE
