Shihlin electric SE3 Series User Manual

Communication parameter group07
PARAMETER DESCRIPTION 166
Group
Parameter
Number
Name
Setting Range
Default
Page
07-16
P.801
CANopen rate
3: 125Kbps
0
185
4: 100Kbps
5: 50 Kbps
07-17
P.802
CANopen
communication
status
0: Node retry status
0
185
1: Communication retry status
2: Retry completion status
4: stop state
5: operation status
127: pre-operational status
07-18
P.803
CANopen control
status
0: Boot not completed status
0
185
1: Forbidden operation state
2: Pre-excitation status
3: Excitation state
4: Allowed operating status
7: Quick action stop status
13: Trigger error action status
14: Error status
07-25
P.810
PU communication
protocol selection
0: Modbus protocol
1
168
1: Shihlin protocol
2: PLC protocol (Effective when using Shihlin built-in PLC)
07-26
P.811
PU inverter
communication
station number
0~254
0
168
07-27
P.812
PU Serial
communication
baud rate
0：Baud rate 4800bps
1
169
1：Baud rate 9600bps
2：Baud rate 19200bps
3：Baud rate 38400bps
4：Baud rate 57600bps
5：Baud rate 115200bps
07-28
P.813
PU data length
0：8bit
0
169
1：7bit
07-29
P.814
PU stop bit
0：1bit
0
169
1：2bit
07-30
P.815
PU Parity check
option
0：no parity check
0
169
1：odd check
2：even check
07-31
P.816
PU CR/LF
selection
1: CR only
1
169
2: Both CR and LF
07-32
P.817
PU Modbus
communication
format
0：1、7、N、2 (Modbus, ASCII)
4
169
1：1、7、E、1 (Modbus, ASCII)
2：1、7、O、1 (Modbus, ASCII)
3：1、8、N、2 (Modbus, RTU)
4：1、8、E、1 (Modbus, RTU)
5：1、8、O、1 (Modbus, RTU)
