Shihlin electric SE3 Series User Manual

General specification
INVERTER INTRODUCTION 17
3.1.2 220V series one-phase
Frame
A
B
Model SE3-021-- xy
0.4K
0.75K
1.5K
2.2K
Inverter Output
HD
Rated output capacity
(kVA)
1
1.5
3.2
4.2
Rated output current
(A)
2.7
4.5
8
11
Applicable motor
capacity (HP)
0.5
1
2
3
Applicable motor
capacity (kW)
0.4
0.75
1.5
2.2
Overload current
rating
150% 60 seconds, 200% 3 seconds (inverse-time characteristics)
Carrier frequency
(kHz)
1~15KHz
ND
Rated output capacity
(kVA)
1.2
2
3.4
4.8
Rated output current
(A)
3
5
8.5
12.5
Applicable motor
capacity (HP)
0.5
1
2
3
Applicable motor
capacity (kW)
0.4
0.75
1.5
2.2
Overload current
rating
120% 60 seconds (inverse-time characteristics)
Carrier frequency
(kHz)
1~15KHz
Maximum output
voltage
3 phase 200-240V
Power Supply
Rated input AC voltage/
frequency
Single phase 200-240V 50Hz / 60Hz
Permissible AC voltage
fluctuation
Single phase 170-264V 50Hz / 60Hz
Permissible frequency
fluctuation
±5%
Power supply capacity (kVA)
1.5
2.5
4.5
6.9
Rated input current
(A) *Note 1
HD
5.9
9.7
14.8
23.1
ND
6.7
10.5
17.9
26.3
Cooling method
Self cooling
Fan cooling
Weight (kg)
1.0
1.0
1.5
1.5
Note 1: The value indicates the current at rated output. The rated input current value is not only affected by power transformer, input side reactor, wiring
condition, but also fluctuates with the impedance of the power supply side.
