Appendix 1
APPENDIX 279
Parameter
Number
Group
Name
Setting Range
Default
Page
P.43
03-22
Output frequency detection
for reverse rotation
0~650.00Hz
99999
126
99999: Same as the setting of 03-21(P.42)
P.44
01-22
Second acceleration time
0~360.00s/0~3600.0s
99999
88
99999: Off
P.45
01-23
Second deceleration time
0~360.00s/0~3600.0s
99999
88
99999: Off
P.46
01-24
Second torque boost
0~30.0%
99999
88
99999: Off
P.47
01-25
Second base frequency
0~650.00Hz
99999
88
99999: Off
P.48
07-03
COM1 Data length
0: 8bit
0
168
1: 7bit
P.49
07-04
COM1 Stop bit length
0: 1bit
0
168
1: 2bit
P.50
07-05
COM1 parity check
selection
0: No parity check
0
168
1: Odd
2: Even
P.51
07-06
COM1 CR/LF selection
1: CR only
1
168
2: Both CR and LF
P.52
07-08
COM1 Number of
communication retries
0~10
1
168
P.53
07-09
COM1 communication
interval allowed time
0~999.8s: Checking communication timeout with
the set value
99999
168
99999: No timeout check
P.54
02-04
Terminal AM output
function
0: Output frequency, use 02-51 (P.55) value as
100%.
0
97
1: Output current, use 02-52 (P.56) value as
100%.
2: Output DC bus voltage, use the OV trigger
voltage as 100%.
3: Output inverter temperature accumulate rising
rate, use NTC trigger level as 100%.
4: Output inverter thermal relay accumulate rate,
use the digital thermal relay trigger level ( 06-00
( P.9 ) ≠ 0 ) or the thermal relay on IGBT trigger
level ( 06-00 (P.9) = 0) as 100%.
5: Target frequency, use 02-51(P.55) value as
100%.
6: Fixed output, voltage or current output level
can be set by 02-54 (P.541)
7: Output voltage, use inverter rated voltage as
100%
8: Excitation current, use motor rated current as
100%. (Valid only when 00-21(P.300) or 00-22
(P.370) is set to 3~6)
