Shihlin electric SE3 Series User Manual

Appendix 1
APPENDIX 284
Parameter
Number
Group
Name
Setting Range
Default
Page
P.86
03-02
Terminal RES input
function
Same as 03-00
30
118
P.87
03-14
Digital input logic
0～1023
0
124
P.88
03-15
Digital output logic (with
expansion card)
0～4095
0
124
P.89
13-00
Slip compensation
coefficient
0～10
0
252
P.90
00-00
Inverter model
Read only
Read
62
P.91
01-16
Frequency jump 1A
0～650.00Hz
99999
87
99999: Off
P.92
01-17
Frequency jump 1B
0～650.00Hz
99999
87
99999: Off
P.93
01-18
Frequency jump 2A
0～650.00Hz
99999
87
99999: invalid
P.94
01-19
Frequency jump 2B
0～650.00Hz
99999
87
99999: Off
P.95
01-20
Frequency jump 3A
0～650.00Hz
99999
87
99999: Off
P.96
01-21
Frequency jump 3B
0～650.00Hz
99999
87
99999: Off
P.97
00-17
Second target frequency
selection
0: Frequency set by keypad
0
72
1: Frequency set by RS485 communication
2: Frequency set by analog input
3: Frequency set by communication expansion
card
4: Frequency set by PG card A2 B2
5: Frequency set by HDI pulse
P.98
01-26
Middle frequency 1
0～650.00Hz
3.00Hz
88
P.99
01-27
Output voltage 1 of middle
frequency
0～100.0%
10.0%
88
P.100
04-15
Programmed operation
minute / second selection
0: Select minute as the time increment.
1
134
1: Select second as the time increment.
P.101
04-27
Programmed operation
mode speed 1 operating
time
0～6000.0s
0.0s
135
P.102
04-28
Programmed operation
mode speed 2 operating
time
0～6000.0s
0.0s
135
P.103
04-29
Programmed operation
mode speed 3 operating
time
0～6000.0s
0.0s
135
P.104
04-30
Programmed operation
mode speed 4 operating
time
0～6000.0s
0.0s
135
