Shihlin electric SE3 Series User Manual

Basic parameter group 01
PARAMETER DESCRIPTION 78
Group
Parameter
Number
Name
Setting Range
Default
Page
01-17
P.92
Frequency jump 1B
0～650.00Hz
99999
87
99999: Off
01-18
P.93
Frequency jump 2A
0～650.00Hz
99999
87
99999: Off
01-19
P.94
Frequency jump 2B
0～650.00Hz
99999
87
99999: Off
01-20
P.95
Frequency jump 3A
0～650.00Hz
99999
87
99999: Off
01-21
P.96
Frequency jump 3B
0～650.00Hz
99999
87
99999: Off
01-22
P.44
Second acceleration time
0～360.00s/0～3600.0s
99999
88
99999: Off
01-23
P.45
Second deceleration time
0～360.00s/0～3600.0s
99999
88
99999: Off
01-24
P.46
Second torque boost
0～30.0%
99999
88
99999: Off
01-25
P.47
Second base frequency
0～650.00Hz
99999
88
99999: Off
01-26
P.98
Middle frequency 1
0～650.00Hz
3.00Hz
88
01-27
P.99
Output voltage 1 of middle
frequency
0～100.0%
10.0%
88
01-28
P.162
Middle frequency 2
0～650.00Hz
99999
88
99999: Off
01-29
P.163
Output voltage 2 of middle
frequency
0～100.0%
0.0%
89
01-30
P.164
Middle frequency 3
0～650.00Hz
99999
89
99999: Off
01-31
P.165
Output voltage 3 of middle
frequency
0～100.0%
0.0%
89
01-32
P.166
Middle frequency 4
0～650.00Hz
99999
89
99999: Off
01-33
P.167
Output voltage 4 of middle
frequency
0～100.0%
0.0%
89
01-34
P.168
Middle frequency 5
0～650.00Hz
99999
89
99999: Off
01-35
P.169
Output voltage 5 of middle
frequency
0～100.0%
0.0%
89
01-36
P.255
S curve time at the
beginning of acceleration
0～25.00s/0～250.0s
0.20s
89
01-37
P.256
S curve time at the end of
acceleration
0～25.00s/0～250.0s
99999
89
99999: Off
01-38
P.257
S curve time at the
beginning of deceleration
0～25.00s/0～250.0s
99999
89
99999: Off
01-39
P.258
S curve time at the end of
deceleration
0～25.00s/0～250.0s
99999
89
99999: Off
