Addr. Parameter C Setting Options Default Setting
_:5041:122 Sychr./Asycr.1:Max.
voltage diff. V2>V1
0.000 V to 170.000 V 5.000 V
_:5041:123 Sychr./Asycr.1:Max.
voltage diff. V2<V1
0.000 V to 170.000 V 5.000 V
_:5041:124 Sychr./Asycr.1:Max.
angle diff. α2>α1
0 ° to 90 ° 10 °
_:5041:125 Sychr./Asycr.1:Max.
angle diff. α2<α1
0 ° to 90 ° 10 °
_:5041:121 Sychr./Asycr.1:Delay
close command
0.00 s to 60.00 s 0.00 s
Information List
No. Information Data Class
(Type)
Type
Sychr./Asycr.1
_:5041:81 Sychr./Asycr.1:>Block stage SPS I
_:5041:500 Sychr./Asycr.1:>Selection SPS I
_:5041:502 Sychr./Asycr.1:>Start / stop syn.proc. SPS I
_:5041:503 Sychr./Asycr.1:>Start syn. process SPS I
_:5041:504 Sychr./Asycr.1:>Stop syn. process SPS I
_:5041:506 Sychr./Asycr.1:>Op. mode 'V1<V2>' SPS I
_:5041:505 Sychr./Asycr.1:>Op. mode 'V1>V2<' SPS I
_:5041:507 Sychr./Asycr.1:>Op. mode 'V1<V2<' SPS I
_:5041:508 Sychr./Asycr.1:>Op. mode 'dir.cls.cmd' SPS I
_:5041:501 Sychr./Asycr.1:>Block close command SPS I
_:5041:54 Sychr./Asycr.1:Inactive SPS O
_:5041:52 Sychr./Asycr.1:Behavior ENS O
_:5041:53 Sychr./Asycr.1:Health ENS O
_:5041:328 Sychr./Asycr.1:In progress SPS O
_:5041:324 Sychr./Asycr.1:Release close cmd. SPS O
_:5041:305 Sychr./Asycr.1:All sync. conditio. OK SPS O
_:5041:303 Sychr./Asycr.1:State f-synchronous SPS O
_:5041:325 Sychr./Asycr.1:Voltage difference OK SPS O
_:5041:326 Sychr./Asycr.1:Angle difference OK SPS O
_:5041:327 Sychr./Asycr.1:Frequency diff. OK SPS O
_:5041:307 Sychr./Asycr.1:Cond. V1<V2> fulfilled SPS O
_:5041:306 Sychr./Asycr.1:Cond. V1>V2< fulfilled SPS O
_:5041:308 Sychr./Asycr.1:Cond. V1<V2< fulfilled SPS O
_:5041:309 Sychr./Asycr.1:Frequency f1 > fmax SPS O
_:5041:310 Sychr./Asycr.1:Frequency f1 < fmin SPS O
_:5041:311 Sychr./Asycr.1:Frequency f2 > fmax SPS O
_:5041:312 Sychr./Asycr.1:Frequency f2 < fmin SPS O
_:5041:313 Sychr./Asycr.1:Voltage V1 > Vmax SPS O
_:5041:314 Sychr./Asycr.1:Voltage V1 < Vmin SPS O
_:5041:315 Sychr./Asycr.1:Voltage V2 > Vmax SPS O
_:5041:316 Sychr./Asycr.1:Voltage V2 < Vmin SPS O
_:5041:317 Sychr./Asycr.1:V dif.too large(V2>V1) SPS O
_:5041:318 Sychr./Asycr.1:V dif.too large(V2<V1) SPS O
6.4.8.4
Control Functions
6.4 Synchronization Function
SIPROTEC 5, High-Voltage Bay Controller, Manual 387
C53000-G5040-C015-9, Edition 11.2017
