Addr. Parameter C Setting Options Default Setting
_:5041:117 Sychr./Asycr.1:Max.
frequency diff. f2>f1
0.000 Hzto 4.000 Hz 0.100 Hz
_:5041:118 Sychr./Asycr.1:Max.
frequency diff. f2<f1
0.000 Hzto 4.000 Hz 0.100 Hz
Synchr. op.mode
_:5041:119 Sychr./Asycr.1:Sync. oper-
ating mode
•
off
•
on
on
_:5041:120 Sychr./Asycr.1:f-threshold
ASYN<->SYN
0.010 Hzto 0.200 Hz 0.010 Hz
_:5041:122 Sychr./Asycr.1:Max. voltage
diff. V2>V1
0.000 V to 170.000 V 5.000 V
_:5041:123 Sychr./Asycr.1:Max. voltage
diff. V2<V1
0.000 V to 170.000 V 5.000 V
_:5041:124 Sychr./Asycr.1:Max. angle
diff. α2>α1
0 ° to 90 ° 10 °
_:5041:125 Sychr./Asycr.1:Max. angle
diff. α2<α1
0 ° to 90 ° 10 °
_:5041:121 Sychr./Asycr.1:Delay close
command
0.00 s to 60.00 s 0.00 s
dfdiff/dt limitation
_:140 Adv. options:Limit dfdiff/dt
for sync. op
•
0
•
1
false
_:141 Adv. options:Max. value
dfdiff/dt syn
0.010 Hz/sto 0.025 Hz/s 0.010 Hz/s
_:142 Adv. options:Limit dfdiff/dt
for asyn. op
•
0
•
1
false
_:143 Adv. options:Max. value
dfdiff/dt asyn
0.050 Hz/sto 0.500 Hz/s 0.050 Hz/s
Frequ. oscillations
_:150 Adv. options:Suppr. frequ.
oscillations
•
0
•
1
false
_:151 Adv. options:Max. diff. "f
threshold"
0.000 Hzto 0.100 Hz 0.000 Hz
Information List
No.
Information Data Class
(Type)
Type
Measurements
_:2311:303 General:Multiple selection SPS O
_:2311:304 General:Blocked no V selected SPS O
_:2311:329 General:V1 MV O
_:2311:330 General:f1 MV O
_:2311:331 General:V2 MV O
_:2311:332 General:f2 MV O
_:2311:300 General:dV MV O
_:2311:301 General:df MV O
_:2311:302 General:dα MV O
6.4.16
Control Functions
6.4 Synchronization Function
422 SIPROTEC 5, High-Voltage Bay Controller, Manual
C53000-G5040-C015-9, Edition 11.2017
