Settings
Addr. Parameter C Setting Options Default Setting
Control
_:104 Tap changer:Check
switching authority
•
no
•
yes
•
advanced
yes
_:108 Tap changer:Control
model
•
status only
•
direct w. normal secur.
•
SBO w. normal secur.
•
direct w. enh. security
•
SBO w. enh. security
SBO w. enh.
security
_:109 Tap changer:SBO time-
out
0.01 s to 1800.00 s 30.00 s
_:110 Tap changer:Feedback
monitoring time
0.01 s to 1800.00 s 10.00 s
Tap changer
_:111 Tap changer:Maximum
output time
0.02 s to 1800.00 s 1.50 s
_:112 Tap changer:Supervision
behavior
•
off
•
warning
•
alarm block
alarm block
_:113 Tap changer:Motor
supervision time
5 s to 100 s 10 s
_:116 Tap changer:Highest tap
changer pos.
•
Lowest voltage tap
•
Highest voltage tap
Lowest voltage
tap
_:114 Tap changer:Lowest tap
position
-64 to 64 1
_:115 Tap changer:Highest tap
position
-64 to 64 15
Switching authority
_:117 Tap changer:Swi.dev.
related sw.auth.
•
0
•
1
false
_:118 Tap changer:Specific sw.
authorities
•
0
•
1
true
_:119 Tap changer:Specific
sw.auth. valid for
•
station
•
station/remote
•
remote
station/remote
_:120 Tap changer:Num. of
specific sw.auth.
2 to 5 2
_:121 Tap changer:Multiple
specific sw.auth.
•
0
•
1
false
Information List
No.
Information Data Class
(Type)
Type
Tap changer
_:500 Tap changer:>Acquisition blocking SPS I
_:501 Tap changer:>Enable SPS I
_:507 Tap changer:>Sw. authority local SPS I
6.8.4
6.8.5
Control Functions
6.8 Transformer Tap Changers
448 SIPROTEC 5, High-Voltage Bay Controller, Manual
C53000-G5040-C015-9, Edition 11.2017
