SD54634 $SNS_MEA_TP_CAL_MEASURE_DEPTH[n] Distance between the tool probe up‐
per edge and the milling tool lower
edge.
= 2 Default value
MD51752 $MNS_J_MEA_M_DIST_TOOL_LENGTH Measuring path to measure the tool
length.
= 2 Default value
MD51753 $MNS_J_MEA_M_DIST_TOOL_RADIUS Measuring path to measure the tool ra‐
dius.
= 1 Default value
MD51786 $MNS_J_MEA_T_PROBE_MEASURE_DIST Measuring path to calibrate the probe
or for measurements with stationary
spindle.
= 10 Default value
General cycle setting data when measuring with rotating spindle
SD54670 $SNS_MEA_CM_MAX_PERI_SPEED[0] Maximum permissible peripheral
speed of the tool to be measured.
= 100 Default value
SD54671 $SNS_MEA_CM_MAX_REVOLUTIONS[0] Maximum permissible tool speed of the
tool to be measured. The speed is au‐
tomatically reduced when exceeded.
= 1000 Default value
SD54672 $SNS_MEA_CM_MAX_FEEDRATE[0] Maximum permissible feedrate to
probe the tool to be measured at the
probe.
= 20 Default value
SD54673 SNS_MEA_CM_MIN_FEEDRATE[0] Minimum feedrate for the first probing
of the tool to
be measured at the probe.
This avoids excessively small fee‐
drates for large tool radii.
= 1 Default value
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
182 Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3
