SD54674 $SNS_MEA_CM_SPIND_ROT_DIR[0] Spindle direction of rotation to measure
tools.
= 4 Spindle rotation the same as M4 (default value)
Note
If the spindle is already rotating when the measuring cycle is called, this direction of rotation
remains independent of the setting of this data.
SD54675 $SNS_MEA_CM_FEEDFACTOR_1[0] Feedrate factor 1
= 10 Default value
= 0 Only single probing with the feedrate calculated by the cycle. However, as a minimum, the
value from SD54673[0] $SNS_MEA_CM_MIN_FEEDRATE.
>= 1 First probing with feedrate. However, as a minimum with the value from
SD54673[0] $SNS_MEA_CM_MIN_FEEDRATE)
SD54675[0] $SNS_MEA_CM_FEEDFACTOR_1
SD54676 $SNS_MEA_CM_FEEDFACTOR_2[0] Feedrate factor 2
= 0 Second probing with the feedrate calculated by the measuring cycle. This is only effective
for SD54673[0] $SNS_MEA_CM_FEEDFACTOR_1 > 0, default value
>= 1 Second probing with the feedrate from SD54673[0] $SNS_MEA_CM_MIN_FEEDRATE fee‐
drate factor 2.
Third probing with the calculated feedrate.
Note
Feedrate factor 2 should be less than feedrate factor 1.
SD54677 $SNS_MEA_CM_MEASURING_ACCURACY[0] Specified measuring accuracy.
The value of this parameter always
refers to the last probing of the tool
at the probe!
= 0.005 Default value
SD54692 $SNS_MEA_T_CIRCULAR_ARC_DIST Arc distance for the single cutting edge
measurement of the radius.
= 0.25
*)
Default value
Configuring cycles
7.9 Measuring cycles and measurement functions
SINUMERIK Operate
Commissioning Manual, 10/2015, 6FC5397-3DP40-5BA3 183
