01/02
4-51
8825/8830 Printer
REP 9.4
Repairs and Adjustments
Figure 1 Removing the Cleaner Blade
Cleaner Blade
Photoreceptor
Seal Channel
Photoreceptor Seal
Right-hand Seal
Xerographic Module
Frame
Blade Retainer (3)
