01/02
7-89
8825/8830 Printer
Plug/Jack List
Wiring Data
Plug/Jack List
The following list is provided as an aid in locating plugs and jacks and other components.
Refer to the referenced Block Schematic Diagram (BSD) for component location.
Table 1 Plug/Jack
Plug/Jack or Component Brief Description BSD
A1 AC Module BSD 1.1A
A1FL1 Noise Filter “Delta” BSD 1.1A
A1FL1 Noise Filter “Corcom” BSD 1.1B
A1GFP1 Ground Fault Protector BSD 1.1A
A1K1 Fuser Power Relay BSD 10.1
A1K3 Fuser Ballast Power Relay BSD 10.1
A1P2/J2 AC Power Module BSD 10.1
A1P3/J3 Controller Power Cord BSD 1.1A
A1Q1 Fuser Triac BSD 10.1
A1R1 Fuser Ballast Resistor BSD 10.1
A1S1 Main Power Switch BSD 1.1A
A2P201/J201 Driver PWB BSD 7.5
A2P202/J202 Print Length Meter BSD 3.1
A2P203/J203 Driver PWB BSD 7.5
A2P203/J203 Cutter Interlock BSD 7.5
A2P204/J204 Driver PWB BSD 1.4
A2P205/J205 Xerographic HVPS BSD 9.1
A2P206/J206 Driver PWB to Main PWB BSD 3.1
A2P207/J207 Driver PWB BSD1.2
A2P208/J208 Driver PWB BSD 1.2
A2P209/J209 Feed/Rewind Clutches BSD 7.2
A2P210/J210 Media Drive Motor BSD 7.1
A2P210/J210 Transport Drive BSD 8.1
A2P213/J213 Driver PWB (Fuser Control) BSD 10.1
A2P214/J214 Driver PWB BSD 1.2
A2P215/J215 Driver PWB BSD 4.3
A2P216/J216 Driver PWB BSD 1.2
A3P301/J301 Main PWB BSD 2.1
A3P303/J303 Main PWB BSD 9.7
A3P305/J305 Main PWB to Media Buckle Sensor BSD 4.1
A3P306/J306 Main PWB BSD 10.1
A3P307A/J307A Main PWB to Image Bar Assembly BSD 6.1
A3P307B/J307B Main PWB to Controller BSD 3.1
A3P312/J312 Main PWB BSD 1.2
A3P313/J313 Main PWB to Driver PWB BSD 3.1
A5P1/J1 LVPS BSD 1.2
A5P2/J2 LVPS BSD 1.2
A5P3/J3 LVPS BSD 1.2
A7P1/J1 Media Drive Motor PWB BSD 7.1
A7P2/J2 Media Drive Motor PWB BSD 7.1
A8MOT1P1/J1 Cutter Drive Motor BSD 7.5
A8Q1P1/J1 Cutter Home Sensor BSD 7.5
A20MOT1P1/J1 Fuser Roll Drive Motor BSD 4.1
A20MOT2P1/J1 Developer Drive Motor BSD 4.2
A20MOT3P1/J1 Drum Drive Motor BSD 4.3
A21-GRN Transfer Current BSD 9.4
A21-ORN Detack Current BSD 9.4
A21CL1P1/J1 Cut Sheet Roll Drive Clutch BSD 8.1
A21Q1P1 Media Registration Sensor BSD 8.1
A21Q2P1/J1 Sheet Feed Sensor BSD 8.1
A21Q5P1/J1 Media Buckle Sensor BSD 4.1
A21Q5P2/J2 Media Buckle Sensor BSD 4.1
A22MOT1P1/J1 Cartridge Drive Motor BSD 9.7
A22P1/J1 Developer Assembly BSD 9.7
A22Q1P1/J1 Toner Sensor BSD 9.7
A23DS1P1/J1 Erase Lamps BSD 9.6
A23F1 Thermal Fuse BSD 10.1
A23HR1 Fuser Heat Rod BSD 10.1
A23P1/J1 Fuser Heater BSD 10.1
A23P5/J5 Thermistor Pad Assembly BSD 10.1
A24P1/J1 Transport Drive BSD 8.1
A24P2/J2 Transport Drive BSD 8.1
A25P1/J1 Xerographic HVPS BSD 9.1
A25P2/J2 (CHARGE) Xerographic HVPS BSD 9.1
A25P3/J3 (GRID) Xerographic HVPS BSD 9.1
A25P5/J5 (TRANSFER) Xerographics HVPS BSD 9.8
A25P6/J6 (DETACK) Xerographics HVPS BSD 9.8
A29CN2/A30P2 LED Driver (Data) BSD 6.1
A29CN3/A30J3 LED Driver (Data) BSD 6.2
A29P1/CN1 LED Drive (Power) BSD 6.1
A29P4/CN4 LED Driver (Power) BSD 6.2
A30J3/A29CN3 LED Driver (Data) BSD 6.2
A30P1/J1 Receiver PWB to Main PWB BSD 6.1
A30P2/A29CN2 Receiver PWB to LED Driver PWB BSD 6.1
A32P1/J1 User Interface PWB to Main PWB BSD 2.1
A32P2/J2 User Interface PWB to 2x40 Display BSD 2.1
CL1P1/J1 Roll 1 Feed Clutch BSD 7.2
CL2P1/J1 Roll 1 Rewind Clutch BSD 7.2
Table 1 Plug/Jack
Plug/Jack or Component Brief Description BSD
