01/02
2-4
8825/8830 Printer
C1-59/ C2-59/ C3-59 RAP
Status Indicator RAPs
C1-59/ C2-59/ C3-59 RAP
NOTE: C1, C2, C3 means Roll 1, 2, or 3.
The Media Drive Motor (MOT1, BSD 7.1) was trying to feed the Roll x Media forward to the
registration position but the Position Sensor (Q1, Q2, or Q3, BSD 7.2, 7.3, 7.4) sensed that the
media jammed. The problem may be caused by light reflecting off of media, the media drawer,
or baffles and returning to the media Position Sensor.
Initial Actions
• Check that the Roll 1, 2, or 3 (the Drawer that was in use when the fault occurred) Posi-
tion Sensor Q1, Q2, or Q3 is not blocked by a piece of media.
• Ensure that there are no strips or pieces of media in the area of the Position Sensor Q1,
Q2, or Q3.
Procedure
Enter DIAGNOSTICS (General Procedures). Enter [0703] (ROLL FEED MOTOR FOR-WARD)
and observe the Media Drive Motor. The Media Drive Motor runs.
YN
Check that the Media Drawers are closed. Check the operation of the Drawer Interlock
Switched as follows:
Enter [0713] for Drawer 1
Enter [0714] for Drawer 2
Enter [0715] for Drawer 3
Repair the Interlock Switch as required.
Check the rear of the appropriate Drawer and the baffles that are located around the opening
of the Position Sensor for shinny or reflective surfaces. If these conditions exist correct the
problem by painting the surface with flat black paint or use a black marker to cover the surface.
Table 1 Media Roll
Roll 1 BSD 7.2
Roll 2 BSD 7.3
Roll 3 BSD 7.4
To Next Page
