01/02
3-20
8825/8830 Printer
PQ 22
Print Quality
PQ 22 Offsetting
Table 1 Offsetting Symptom / Check
Symptom/ check
Offsetting is the result of toner
adhering to the Fuser Heat
Roll and transferring to subse-
quent prints.
Probable Cause Corrective Action
1. There is insufficient fuser
oil on the Heat Roll.
1A. Check/replace the Web
Oiler ( REP 10.7).
1B. Check/adjust oil dispense
rate [10-32].
2. The fuser temperature is
out of specification.
2. Check Fuser Temperature
( ADJ 10.1).
3. The Fabric Guide is not
contacting the Fuser Heat Roll
uniformly.
3. Check / replace the Fabric
Guide ( REP 8.9) and Pres-
sure Plates ( REP 8.5).
4. Media is damp. 4A. Ensure that the media is
stored correctly.
4B. Refer to BSD 7.1 and
BSD 7.3 to check for correct
operation of the paper heat-
ers.
5. Damaged or contaminated
heat roll
5. Clean or replace the Heat
Roll ( REP 10.2).
To Next Page
