01/02
1-12
8825/8830 Printer
Message Display Entry Chart, Maintenance Proce-
Service Call Procedures
NOTE: Substitute 1, 2, or 3 for X depending on which status code is displayed.
Maintenance Procedures
ALL ROLLS ARE
EMPTY
Media Registration
Sensor failed to
sense media.
Go to C1-04.
Table 1 Message Display Entry Chart
Table 1 Image Module
INTER
VAL
TASK REASON TASK ENABLER
Nor-
mal
Call
Check, clean, or
repair spacing
wheels as
required.
Contaminated, dirty or
worn spacing wheels or
drum ends cause print
quality defects.
Clean or replace spacing wheels and
the end surface that the wheels ride
on.
Nor-
mal
Call
Check and clean, if
required, the
scorotron.
Contaminated grid, bent
or contaminated pins.
Worn end blocks, are
also causes for scorotron
failure, which results in
print quality defects.
WARNING
The scorotron pin arrays are very
sharp. Use care when handling the
assembly.
If contaminated, remove scorotron
assembly and clean both sides of the
grid with a brush. Examine pins and
clean with brush Only if contami-
nated. Cleaning with a cloth can
deposit lint that will cause print qual-
ity problems.
Nor-
mal
Call
Clean the image
bar.
Contamination causes
print quality defects.
Clean the image bar with a lint free
cloth and lens cleaner.
As
Requir
ed
Repair or replace
the scorotron/grid.
Contamination causes
print quality defects.
WARNING
The scorotron pin arrays are very
sharp. Use care when handling the
assembly.
Replace the grid and/or pin array.
Perform ADJ 9.2 Electrostatic
Series.
Table 2 Xerographic Module
INTER
VAL
TASK REASON TASK ENABLER
To Next Page
