01/02
6-53
8825/8830 Printer
Product Specifications
General Procedures
Product Specifications
Physical Characteristics
( Figure 1): Printer front dimensions
Figure 1 Printer Front Dimensions
Minimum Space Requirements
( Figure 2): Printer footprint
Figure 2 Printer Footprint
Electrical Specifications
The printer is designed to operate on a 20 Amp, 105 - 125 VAC, 60 Hz single phase dedicated
line protected by a circuit breaker.
Power Cord Length: 10 feet (3 m)
Table 1
Printer Dimensions
Weight 8830 650 lbs (295 kg)
8825 (1 drawer) 620 lbs (281 kg)
8825 (2 drawer) 635 lbs (286 kg)
Height 43 inches (1092 mm)
Width 23 inches (584 mm)
Depth 57 inches (1448 mm)
Product Code 8YG
43”
(1092 mm)
57” (1448 mm)
Table 2
Current Consumption:
Rest 1.0 Amps
Standby 1.4 Amps
Ready 6.0 Amps
Running 16.0 Amps
Table 3
Power Consumption:
Rest 120 Watts
Standby 1000 Watts
Ready 690 Watts
Running 1840 Watts
24”
24”
(610 mm)
(610 mm)
36”
36”
(914 mm)
(914 mm)
117” (2972 mm)
83” (2108 mm)
