01/02
6-54
8825/8830 Printer
Product Specifications
General Procedures
Environmental Conditions
Temperature:
Maximum 80
°F (27°C)
Minimum 60
°F (10°C)
Humidity:
Maximum 80%
Minimum 20%
Maximum Elevation:
7000 feet (2133 m)
Roll Size Width: 11” (279.4 mm) 36” (914.4 mm)
Roll Size Diameter: 3” (76.2 mm) to 6.7” (170.2 mm)
Output Print Specifications:
Cut Sheet Minimum Size - 8.5 X 11” (216 X 279 mm) Portrait)
Roll Sheet Minimum Size - 11” X 8.5” (279 X 216 mm) Landscape
Maximum Size 36” X 48 feet (914 mm X 12.2 m)
80 feet (24.4 m) Optional
Table 4
Heat Emission (BTU/Hr):
Rest 393
Standby 550
Ready 2350
Running 6270
Table 5
Media Specifications
Bond 20 Lb
Vellum 20 Lb
Film 4 mil
Tracing 4 mil
