01/02
5-37
8825/8830 Printer
PL 10.1
Parts Lists
PL 10.1 Xerographic Module
Assembly
Item Part Description
1 126K05992 Xerographic Module Assembly (60
Hz) (REP 9.1)
– 126K07152 Xerographic Module Assembly (50
Hz) (REP 9.1)
2 127E10331 Fuser Drive Motor
3 007E44391 Drive Pulley (28T)
