01/02
4-74
8825/8830 Printer
REP 9.13, REP 9.14
Repairs and Adjustments
Figure 2 Reinstalling the Sump Shield in the Developer Module
REP 9.14 Cartridge Drive Plate
Parts List on PL 9.9
WARNING
Switch off the Main Power Switch. Disconnect the Power Cord.
NOTE: The art used for this procedure was developed for previous products and may not
match the 8825/8830 configuration exactly.
Removal
1. Remove the Developer Module (REP 9.5).
1
Reinstall the Sump
Shield
2
Reinstall the Sump
Shield under the edges
on the housing
To Next Page
