01/02
7-90
8825/8830 Printer
Plug/Jack List
Wiring Data
CL3P1/J1 Roll 2 Feed Clutch BSD 7.3
CL4P1/J1 Roll 2 Rewind Clutch BSD 7.3
CL5P1/J1 Roll 3 Feed Clutch BSD 7.4
CL6P1/J1 Roll 3 Rewind Clutch BSD 7.4
MOT1-3 and -4 Cooling Fan Motor BSD 1.4
MOT2-1 and -2 Cooling Fan Motor BSD 1.4
Q1P1/J1 Roll 1 Position Sensor BSD 7.2
Q2P1/J1 Roll 2 Position Sensor BSD 7.3
Q3P1/J1 Roll 3 Position Sensor BSD 7.4
Q4P1/J1 Roll 1 Motion Sensor BSD 7.2
Q5P1/J1 Roll 2 Motion Sensor BSD 7.3
Q6P1/J1 Roll 3 Motion Sensor BSD 7.4
S1 Cutter Cover Interlock Switch BSD 1.3
S1 Drawer 1 Reed Switch BSD 7.1
S2 Drawer 2 Reed Switch BSD 7.1
S3 Drawer 3 Reed Switch BSD 7.1
S21 Front Door Interlock Switch BSD 1.3
S26 Top Cover Interlock Switch BSD 1.3
S29 Feed Shelf Interlock Switch BSD 1.2
Table 1 Plug/Jack
Plug/Jack or Component Brief Description BSD
